Fig. 1

ID
ZDB-IMAGE-210403-68
Genes
Source
Figures for Kesavan et al., 2020
Figure Caption

Fig. 1

Expression of ism1 and ism2 during zebrafish embryogenesis. Whole mount ISH was performed at the indicated stages during zebrafish embryogenesis with riboprobes against ism1 (panels as; detected in purple), fgf8 (panels lp, detected in red) and ism2 (tv; detected in purple). a, b, e, g Lateral views, dorsal to the right; c animal view, shield to the right; d corresponding dorsal view, animal to the top; f, h animal-dorsal views; i lateral view, anterior to the left; j, k corresponding dorsal views; l, m flat-mounted embryos, dorsal view, anterior to the left; np transverse sections at indicated positions in panels l and m. qt, v Lateral views, anterior to the left. u Dorsal view, anterior to the left. Stages are indicated as % epiboly or as sph: sphere stage, sh: shield stage, tb: tailbud stage; ss: somite stage (5, 10, 18ss correspond to 5, 10, or 18 somite stage). Arrowheads in a, b, and c represent dorsal expression domain; arrows in e and f represent expression around YSL nuclei; white asterisks in i and m correspond to presomitic mesoderm; black arrowhead in j and s point to axial mesoderm/notochord; white arrowhead in k points to adaxial cells; white arrowhead in l and n corresponds to head mesenchyme; arrows in l point to ism1 expression close to Kupffer’s vesicle; asterisks in q and s represent tailbud; red asterisks in l, m, q, and r correspond to the MHB; arrowhead in t points to expression in the nasal primodium; arrowheads in v represent scattered expression in the trunk; arrows in v point to expression in the tailfin bud. Scale bar: 200 μm in ae and ik; 100 μm in fh, q, nr, and rv

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Cell Tissue Res.
