Figure Caption
Fig. 5
Expression patterns of SNAI1, HMGA2, and VAV2 during zebrafishembryonic development. WISH results demonstrating the expression of SNAI1 (A), HMGA2 (B), and VAV2 (C) in wild-type zebrafish at the different stages (20 hpf, 24 hpf, 30 hpf, 48 hpf, and 72 hpf). The numbers shown in the bottom corner indicate the number of embryos with similar staining patterns out of the total number of embryos examined. All images are lateral views, rostral to the left.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ EBioMedicine
