ZFIN Image: Nica et al., 2006, Fig. 5


Figure Caption

Fig. 5 eya1 is required in adenohypophyseal cells. All panels show heads of chimeric zebrafish embryos at 32 hpf, with pomc transcripts in blue and transplanted wild-type cells in brown. (A, C, E) Ventral view, anterior to the top; (B, D, F) lateral view, anterior to the left. Inset in panel F shows magnified view of pituitary. Arrowheads in panels B, D, F point to pomc-positive cells in arcuate nucleus (ventral diencephalon) (Herzog et al., 2003), arrows in panels E, F to pomc-positive cells in adenohypophysis. Note that many, but not all of the transplanted wild-type cells in the adenohypophysis of the eya1 mutant in panels E, F display pomc expression. pomc-negative wild-type cells most likely represent other cell types (lactotropes, somatotropes, thyrotropes, and/or gonadotropes). Scale bars are 50 μm.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 292(1), Nica, G., Herzog, W., Sonntag, C., Nowak, M., Schwarz, H., Zapata, A.G., Hammerschmidt, M., Eya1 is required for lineage-specific differentiation, but not for cell survival in the zebrafish adenohypophysis, 189-204, Copyright (2006) with permission from Elsevier. Full text @ Dev. Biol.
