ZFIN ID: ZDB-FIG-210819-23
Zhao et al., 2020 - Twist3 is required for dedifferentiation during extraocular muscle regeneration in adult zebrafish. PLoS One   15:e0231963 Full text @ PLoS One
ADDITIONAL FIGURES
PHENOTYPE:
Fish:
Knockdown Reagents:
Observed In:
Stage: Day 5

Fig. S2 Tg(α-actin::EGFP) embryos that were injected with twist 1a/b, 2, or 3 MO at the one- to four-cell state demonstrated EOM formation at 5 dpf from dorsal (B-D), lateral (B'-D'), Ventral (B''-D''), and phenotype (B‴-D‴) compared with control embryos (A-A‴). SO: Superior Oblique, SR: Superior Rectus, LR: Lateral Rectus, IO: Inferior Oblique, IR: Inferior Rectus. Asterisk: undeveloped jaw muscle, red arrow: incorrectly inserted EOM, scale bar: 100μm.

Gene Expression Details No data available
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
zf13Tg + MO2-twist1a + MO4-twist1b standard conditions Day 5 eye decreased size, abnormal
Day 5 mandibular muscle morphology, abnormal
Day 5 pericardium edematous, abnormal
Day 5 post-vent region morphology, abnormal
Day 5 trunk morphology, abnormal
zf13Tg + MO2-twist2 standard conditions Day 5 extraocular musculature position, abnormal
Day 5 eye decreased size, abnormal
Day 5 head muscle morphology, abnormal
Day 5 pericardium edematous, abnormal
Day 5 post-vent region morphology, abnormal
Day 5 trunk morphology, abnormal
zf13Tg + MO3-twist3 standard conditions Day 5 dorsal oblique extraocular muscle morphology, normal
Day 5 dorsal rectus morphology, normal
Day 5 eye decreased size, abnormal
Day 5 eye protruding, abnormal
Day 5 lateral rectus morphology, normal
Day 5 pericardium edematous, abnormal
Day 5 post-vent region morphology, abnormal
Day 5 trunk morphology, abnormal
