ZFIN ID: ZDB-FIG-200103-5
Zhang et al., 2019 - Expression analysis of Rab11 during zebrafish embryonic development. BMC Developmental Biology   19:25 Full text @ BMC Dev. Biol.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Fish:
Anatomical Terms:
Stage Range: 64-cell to Day 4

Fig. 5

Whole mount in situ and transverse section hybridization analysis of rab11bb in zebrafish embryos. A 64 cell, lateral view. B 20 hpf, lateral view, arrowheads indicate brain and spinal cord. C 24 hpf, lateral view, arrowheads indicate brain and spinal cord. D 36 hpf, lateral view, arrowheads indicate spinal cord. D’ 36 hpf, dorsal view, red arrowheads indicate spinal cord, green arrowheads indicate pronephric duct. E 48 hpf, lateral view, arrowhead indicates brain. E’ 48 hpf, dorsal view. F 72 hpf, lateral view, arrowhead indicates ear. F’ 72 hpf, dorsal view. G 4 dpf, lateral view, arrowhead indicates pharyngeal arches. G’ 96 hpf, dorsal view, arrowhead indicates retina. H 48 hpf, the trunk transverse section of the embryonic forebrain, arrowheads indicate cerebral cortex. H’ 48 hpf, the trunk transverse section of the embryonic midbrain, arrowheads indicate cerebral cortex. H” 48 hpf, the trunk transverse section of the embryonic hindbrain, arrowheads indicate cerebral cortex. I 48 hpf, lateral view, embryos stained with the sense rab11bb probe

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
rab11bb WT standard conditions 64-cell Not Detected blastodisc ISH
20-25 somites brain ISH
20-25 somites spinal cord neural tube ISH
Prim-5 brain ISH
Prim-5 spinal cord ISH
Prim-25 brain ISH
Prim-25 spinal cord ISH
Long-pec brain ISH
Long-pec dorsal telencephalon distal margin ISH
Long-pec inner ear ISH
Long-pec retina ISH
Protruding-mouth brain ISH
Protruding-mouth inner ear ISH
Protruding-mouth retina ISH
Day 4 brain ISH
Day 4 pharyngeal arch ISH
Day 4 pharyngeal arch 3-7 ISH
Day 4 retina ISH
Antibody Labeling Details No data available
Phenotype Details No data available
