Fig. S15

Overexpression of ß-catenin partially rescues AP patterning in MZdvl2;MZdvl3a mutants.

Embryos at 1-cell stage derived from crosses between female mdvl2^+(-)/-;dvl3a^-/- fish and male dvl2^+/-;dvl3a^-/- fish were injected with ΔN-ß-catenin mRNA (50 pg). Following in situ hybridization or phenotype analysis, the embryos were subjected to genotyping. (A-F) ΔN-ß-catenin partially rescues axin2 and tbx16l expression in MZdvl2;MZdvl3a mutants. Arrowheads indicate the axin2 anterior expression domain. (G-I) ΔN-ß-catenin partially rescues tail development in Zdvl2;MZdvl3a mutants (arrow). Scale bar: (A-F) 400 μm; (G-I) 400 μm.
