Fig. 4

Apoptosis is increased in lama1^UW1 mutant embryos but is not the underlying cause of morphogenesis defects. (A-A′′) Control embryos show little apoptotic cell death. (B-B′′) lama1^UW1 mutant embryos contain a significant number of dying cells. (C-C′′) Injection of Bcl-xL RNA (100 pg) rescues apoptosis in lama1^UW1 mutant embryos, however optic cup morphogenesis defects are still apparent. (A,B,C) Antibody staining for activated caspase-3. (A′,B′,C′) TOPRO-3 counterstain for nuclei. (A′′, B′′, C′′) Merged images. dashed blue line, boundary of optic cup. Dorsal views; scale bar, 50 µm. br, brain; nr, neural retina; le, lens. A, anterior; P, posterior; M, medial; L, lateral.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	lama1^uw1/uw1
Observed In:	optic cup apoptotic process
Stage:	Prim-5

Phenotype Detail
