Fig. 3

admp expression in positively regulated by Nodal signaling, Bozozok, and Chordin: (A–C,J) wild-type, (D–F) mzoep; (G–I) boz^m168; (K,L) din^tt250. (A,G) 40% epiboly, animal view; (D) 45% epiboly, animal view; (B,E,H) 70% epiboly, animal view; (C,F,I,L) 70% epiboly, lateral view; (J,K) 70% epiboly, dorsal view. Note that in the din mutant shown in L, admp expression is restricted to the mesoderm in the inner cell layers, whereas the neuroectoderm in the outer cell layers lacks admp transcripts (in contrast to the wild-type [WT] sibling shown in C).

Expression Data

Gene:	admp
Fish:	WT chrd^tt250/tt250 dharma^m168/m168 tdgf1^{unspecified/unspecified}
Anatomical Terms:	anterior presumptive neural plate presumptive shield shield
Stage Range:	30%-epiboly to Shield

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
