ZFIN ID: ZDB-FIG-091216-26
Peal et al., 2009 - Chondroitin sulfate expression is required for cardiac atrioventricular canal formation. Developmental dynamics : an official publication of the American Association of Anatomists   238(12):3103-3110 Full text @ Dev. Dyn.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Antibody:
Fish:
Anatomical Terms:
Stage Range: Prim-5 to Protruding-mouth

Fig. S1 Expression of chondroitin sulfate in whole mount zebrafish. Animals were stained with an antibody reactive to chondroitin sulfate. Dynamic changes in body expression patterns include early expression within the developing cardiovascular system (vas) and head, followed by later expression within the lateral line neuromasts (n), the pectoral fins (p), otic placodes (0), and pharyngeal arches.

Gene Expression Details No data available
Antibody Labeling Details
Antibody Assay Fish Conditions Stage Anatomy
Ab-CS-56 IHC AB/TU standard conditions Prim-5 - Prim-25 cardiovascular system
IHC Prim-5 - Prim-25 head
IHC Long-pec neuromast
IHC Long-pec otic vesicle
IHC Protruding-mouth pectoral fin
IHC Protruding-mouth pharyngeal arch
Phenotype Details No data available
