Fig. 3a
- ID
- ZDB-FIG-090831-28
- Publication
- Berberoglu et al., 2009 - fezf2 expression delineates cells with proliferative potential and expressing markers of neural stem cells in the adult zebrafish brain
- Other Figures
- All Figure Page
- Back to All Figure Page
fezf2 is expressed in radial glial cells of the telencephalic ventricular zone, which colocalize with markers of neural stem cells and proliferation. (A) Coronal section through telencephalon showing double-label of fezf2-GFP (green) and Hu (red) (20x magnification). (A′–A′″) Closer view of the boxed region (100x magnification) shows that fezf2-GFP+ cells have radial glial morphology (A′) and do not overlap with neuronal marker HuC/D (A″′). (B) Coronal section through telencephalon showing colocalization of fezf2-GFP (green) and BLBP (red) in the pallial ventricular zone (20x magnification). (B′–B″′) Single confocal Z-section (∼0.5 μm) of the boxed region (100x magnification) shows that fezf2-GFP expression colocalizes precisely with BLBP+ radial glial cells. (C) Coronal section through anterior telencephalon showing double-label of fezf2-GFP (green) and GFAP (red) (20x magnification). (C′–C′″) Single confocal Z-section of the boxed region (40x magnification) shows that fezf2-GFP+ cells colocalize with neural stem cell marker GFAP. (D) Coronal section through telencephalon showing colocalization of fezf2-GFP (green) and Sox3 (red) in the pallial ventricular zone (20x magnification). (D′–D″′) Single confocal Z-section of the boxed region shows that fezf2-GFP+ radial glial cells colocalize with neural stem cell marker Sox3 (100x magnification). |
| Gene: | |
|---|---|
| Fish: | |
| Anatomical Terms: | |
| Stage: | Adult |
Reprinted from Gene expression patterns : GEP, 9(6), Berberoglu, M.A., Dong, Z., Mueller, T., and Guo, S., fezf2 expression delineates cells with proliferative potential and expressing markers of neural stem cells in the adult zebrafish brain, 411-422, Copyright (2009) with permission from Elsevier. Full text @ Gene Expr. Patterns
