Figure 3.

Figure 3. Midface development requires dact1 and dact2.

(A) Representative brightfield images of wildtype and dact1/2−/− compound mutants at 4 dpf. 100 individuals were analyzed from a dact1/2+/- double het cross. Lateral and ventral views show dact1/2−/− compound mutants have a hypoplastic midface, medially displaced eyes, and a displaced lower jaw. (B) Representative flat-mount images of Alcian blue stained ethmoid plate (EP) and visceral cartilage (VC) elements from 4 dpf wildtype and dact1/2−/− compound mutants. dact1/2−/− mutants have a rod-shaped EP with no distinct lateral and medial elements. No obvious differences were found in dact1/2 mutant VC. (C) Representative brightfield image of 4 dpf wildtype and dact1/2−/− mutant. Bar indicates vertebral spine length. Scale bar: 100 μm. (D) Representative images of Alcian blue stained dact1/2−/−, wnt11f2−/−, and wnt11f2−/−,dact1/2−/− compound mutants. Embryos resulted from a dact1+/-,dact2+/-,wnt11f2+/-in-cross. Lateral and ventral views show similar craniofacial phenotypes in each mutant. (E) Representative flat-mount images of Alcian blue stained EP show a similar phenotype between dact1/2−/−, wnt11f2−/−, and wnt11f2−/−,dact1/2−/− compound mutants. Scale bar: 200 μm.
