ZFIN Image: Hahn et al., 2020, Figure 1


Figure Caption

Figure 1 Early expression of <italic>ntrk1</italic> is seen in the head and spinal cord using whole mount in situ hybridization at 16.5 hpf and 24 hpf.

(A and D) Expression of ntrk1 is seen at 16.5 hpf is seen in two sets of cranial ganglia (arrow in A and arrows in B). (B, C, E and F) At 24 hpf, expression is seen in two sets of cranial ganglia (arrows) as well as in the RB neurons (arrowheads). (A, B, C and F) Lateral view. (D and E) Dorsal view. All embryos are oriented with the head to the left. hb, marks the hindbrain, and ye, marks the yolk extension. Data are representative of three rounds of in situ hybridization with least 25 embryos per round.

Figure Data

Expression / Labeling details
