ZFIN Image: Kidwell et al., 2018, Fig. 5


Figure Caption

Fig. 5

atoh1c is required for cerebellar granule cell fate. A-D: Reduction in the number of mature GCs in atoh1c mutant as indicated by decreased staining for cerebellin12 (B) and vglut1 (D), at 5 dpf. E-H: The majority of mutant cells expressing Tg(atoh1c::kaede) remain as a non-migrated population in the URL at 3 dpf (G, G? compare to wild-type in E, E?) and 5 dpf (H, H? compare to wild-type in F, F?). I-J: Upregulation of atoh1c mRNA in URL at 5 dpf in atoh1c mutant embryos (J, J? compare to I, I?). Dorsal (A,B,C,D,E,F,G,H,I,J), ventral (A?,B?) and lateral (A?,B?,C?,D?,E?,F?,G?, H?,I?,J?) views are shown with anterior to the left. Scale bars: 50??M.

Figure Data

Expression / Labeling details

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 438(1), Kidwell, C.U., Su, C.Y., Hibi, M., Moens, C.B., Multiple zebrafish atoh1 genes specify a diversity of neuronal types in the zebrafish cerebellum, 44-56, Copyright (2018) with permission from Elsevier. Full text @ Dev. Biol.
