ZFIN Image: Diotel et al., 2015, Fig. 5


Figure Caption

Fig. 5 znf238 is not expressed in radial glial cells but in neurons. A to I: znf238 in situ hybridization (red) followed by S100β (green) immunohistochemistry in the telencephalon. D to F: high magnification views of the corresponding white boxes in A to C. The arrows show that the S100β-positive radial glial cells do not express (or only barely for few of them) znf238 mRNA in the dorsomedian telencephalon. J to L: znf238 in situ hybridization (red) followed by HuC/D (green) immunohistochemistry in the telencephalon. Znf238 transcripts were detected in HuC/D-positive neurons (arrows) Scale bar: 12 µm (J to L); 20 µm (D to I); 70 µm (A to C).

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 19(1-2), Diotel, N., Beil, T., Strähle, U., Rastegar, S., Differential expression of id genes and their potential regulator znf238 in zebrafish adult neural progenitor cells and neurons suggests distinct functions in adult neurogenesis, 1-13, Copyright (2015) with permission from Elsevier. Full text @ Gene Expr. Patterns
