Figure Caption
Fig. 6 Activity of sox9a is not required for the specification or migration of cranial neural crest. (A,B) Wild type (WT) embryos. (C,D) Homozygous jeftw37 embryos. (E,F) Homozygous jefhi1134 embryos. (A,C,E) sox9a expression. (B,D,F) dlx2 expression. All animals were 24 hpf. Dorsal views, anterior towards the left.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
