Fig. S6

Perturbing Rab23 activity in zebrafish does not affect early nodal signaling or general morphology of the embryo.

(A-H) Rab23 overexpression has no effect on early Nodal signaling in zebrafish embryos. The Nodal target genes goosecoid (A-D) and no-tail (E-H) are expressed normally in Q68L-rab23 injected embryos at 40-50% epiboly (A,B, E, F) and 90% epiboly (C, D, G, H) compared to control embryos. (I) Overexpression or knockdown of Rab23 does not affect general size or morphology. Images of live embryos injected with Q68L-rab23 mRNA (C,D) or rab23-atgMO (E,F) at 22 hpf and 48 hpf show no morphological abnormalities compared to control embryos injected with phenol red (A,B).

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 391(2), Fuller, K., O'connell, J.T., Gordon, J., Mauti, O., Eggenschwiler, J., Rab23 regulates Nodal signaling in vertebrate left-right patterning independently of the Hedgehog pathway, 182-195, Copyright (2014) with permission from Elsevier. Full text @ Dev. Biol.
