Figure Caption
Fig. S5
Shh signaling activity is reduced in sulf1-depleted zebrafish embryos. (A-F) Expression of ptch2 at 16hpf (A,D), 24hpf (B,E) and 36hpf (C,F) in embryos injected with ctrlMO (A-C) and sulf1MO (D-F). (G,H) Expression of ptch2 at 24hpf in wild-type (G) and sulf1sa199-/- (H) embryos. Note reduction in ptch2 expression both in sulf1MO-injected and sulf1sa199-/- embryos at 24hpf. Scale bar = 20μm.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
