Fig. S2 Expression of smoc2, meis1, meis2a, and vgll4l at 24 and 48hrs of zebrafish development. All images are lateral views, anterior to the left. A, C, E, G are 24 hpf and B, D, F, H are 48 hpf. A, B) At 24 hpf, smoc2 is expressed in specific brain regions as well as tail mesoderm, including somites and notochord. At 48 hpf, smoc2 expression resolves to the brain and pharyngeal pouches. C, D) meis1 is expressed in the hindbrain and spinal cord as well as the olfactory bulb and retina at 24hpf. Expression is also observed in the retina and branchial arches at 48hpf. E, F) meis2a is expressed in the midbrain, hindbrain and spinal cord as well as the olfactory bulb at 24 hpf. By 48 hpf, expression expands to include the branchial arches. G, H) At 24-48 hpf, vgll4l is expressed in the nose, pharyngeal pouches, lateral line, epidermis and pronephric duct. (All images taken from ZFIN with permission from Thisse et al., 2001 - Expression of the zebrafish genome during embryogenesis (NIH R01 RR15402). ZFIN Direct Data Submission).
