Figure Caption
Fig. S3 Injection of the Gata6-TPmiR145 target protector morpholino mimics the miR-145 morphant phenotype. (A and B) Gata6-TPmiR145 target protectorinjected embryos display gut morphological defects and pericardial edema (arrowhead) at 96 hpf as compared to uninjected wild-type embryos. Expression of gata6 (C and D) and sm22α-b (E and F) is increased in Gata-6-TPmiR145 morphants. Arrows, gut. (Scale bars, 200 μm.)
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Proc. Natl. Acad. Sci. USA
