Fig. S2

ID
ZDB-IMAGE-101013-29
Genes
Source
Figures for Lister et al., 2006
Figure Caption

Fig. S2 Morpholino knockdown effect on neural crest markers. A-B, 6 somite stage. Viewed dorsally, anterior to the left. In situ hybridization for A) tfap2, B) foxd3. C-D) 18 somite stage, lateral views. In situ hybridization for C) mitfa, D) foxd3. Note expression of foxd3 is greater in morpholino-injected embryos than in controls (arrowheads).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 290(1), Lister, J.A., Cooper, C., Nguyen, K., Modrell, M., Grant, K., and Raible, D.W., Zebrafish Foxd3 is required for development of a subset of neural crest derivatives, 92-104, Copyright (2006) with permission from Elsevier. Full text @ Dev. Biol.
