ZFIN Image: Veldman et al., 2010, Fig. S5


Figure Caption

Fig. S5 KLF6a and KLF7a are induced in regenerating RGCs following optic nerve injury, but only KLF7a is expressed in differentiating RGCs. (A and B) In situ hybridization showing KLF6a induction in retinal ganglion cells 3 days post-optic nerve crush (B) as compared to uninjured retina (A). (C and D) In situ hybridization showing KLF7a induction in retinal ganglion cells 3 days post-optic nerve crush (D) as compared to uninjured retina (C). (E) KLF6a is not expressed in the retina at 48 h post fertilization (hpf). (F) KLF7a is expressed in the differentiating RGCs at 48 hpf. Arrows denote developing GCL. Outer nuclear layer (OLN), inner nuclear layer (INL), and ganglion cell layer (GCL).

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Molecular and cellular neurosciences, 43(4), Veldman, M.B., Bemben, M.A., and Goldman, D., Tuba1a gene expression is regulated by KLF6/7 and is necessary for CNS development and regeneration in zebrafish, 370-383, Copyright (2010) with permission from Elsevier. Full text @ Mol. Cell Neurosci.
