ZFIN Image: Sato et al., 2005, Fig. 1


Figure Caption

Fig. 1 Two distinct types of OSNs with different molecular signatures in zebrafish OE. A-J, RNA in situ hybridization was performed on horizontal sections of the zebrafish olfactory rosette using digoxigenin-labeled probes specific for the following molecules: zOMP (A, B), zCNGA2 (C), zOR2.1 (D), zOR13.1 (E), zTRPC2 (F, G), zVR5.3 (H), zVR3.13a (I), and zVR3.13b (J). Note that zOMP (B), zCNGA2 (C), and OR-type receptors (D, E) were expressed in the deep layer of the OE, whereas zTRPC2 (G) and VR-type receptors (H-J) were expressed in the superficial layer. In contrast to the zVR5.3 expression in a large fraction of OSNs (H), other VR- and OR-type receptors were expressed in a small subset of OSNs (D, E, I, J). B-E, G-J, The apical surface of the OE is at the top of each panel. Scale bars: (in F) A, F, 100 μm; (in J) B-E, G-J, 20 μm.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ J. Neurosci.
