ZFIN Image: Shimizu et al., 2005, Fig. 8


Figure Caption

Fig. 8 Cell adhesion between the deep cells and the enveloping layer is disrupted in cdh1 morphant embryos. Wild-type control (wt, A, C, E, G) and cdh1 morphant embryos (MO) embryos (B, D, F, H) were fixed at 8.5 hpf (80% epiboly for the wild-type) and subjected to electron microscopic analysis. Lateral regions. Adhesion between the enveloping layer (EVL) and the deep cells (DCs) was detected in the wild-type control embryos (indicated by arrows in A, C, E), but was severely affected in the cdh1 morphant embryos (arrows in B, D, F). In contrast, the adhesions between the EVL cells (arrowheads in A, C, D) or between the DCs (arrowheads in G, H) were not significantly affected in the cdh1 morphant embryos, compared with the wild-type control embryos.

Figure Data

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Mechanisms of Development, 122(6), Shimizu, T., Yabe, T., Muraoka, O., Yonemura, S., Aramaki, S., Hatta, K., Bae, Y.K., Nojima, H., and Hibi, M., E-cadherin is required for gastrulation cell movements in zebrafish, 747-763, Copyright (2005) with permission from Elsevier. Full text @ Mech. Dev.
