ZFIN Image: Siekmann et al., 2005, Fig. 3


Figure Caption

Fig. 3 Figure 3. Expression of ext1a (A-C,C), ext1b (D,E), and ext1c (F-H) at the 16-somite stage. Anterior of the embryos is to the left. A: Expression of ext1a can be detected in the eye, the dorsal neural tube, Kupffer′s vesicle (black arrow), and the somites. B: Cross-section at the level of the 12th somite. Expression of ext1a can be detected in the anterior hindbrain (arrow) and the dorsal diencephalon (asterisk). C: Dorsal view on the brain of the embryo in A. Krox20 demarcates rhombomeres 3 and 5 (inset). C: Expression of ext1a in the eye, which do not express ext1a. In addition, ext1a transcripts can be detected in two ventromedial (arrowheads) and two dorsomedial (arrows) domains. D: RNA encoding ext1b is expressed more ubiquitously with domains of higher expression in the tailbud region, the eye, and dorsal somites. E: Section at the level of the 9th somite, revealing expression of ext1b in the dorsal aspect of the somite. F: Alternating expression domains of ext1c can be detected in the somites. G: Cross-section of the embryo in F at the level of the 16th somite. H: Cross-section at the level of the 6th somite, revealing expression of ext1c in ventromedial regions of the somites (arrowheads) and adjacent to the neural tube.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
