Figure Caption
Fig. 8 Edn1-deficient ectoderm recapitulates the suc/edn1-/-mutant phenotype. Whole-mount RNA in situ hybridizations (A,B) with immunohistochemistry for biotin-dextran (C,D). (A-C) Dorsolateral views. hand2 expression at 30 hpf (A) is lost in suc;edn1-/- mutants (B). (C) Wild-type embryos that receive ectoderm from suc;edn1-/- donors lose hand2 expression adjacent to the transplanted ectoderm (brown cells, arrow). (D) Transverse cryosection through the arches of the embryo in panel C show that donor cells are confined to ectoderm (arrow, brown cells).
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
