Fig. 4

Cellular distribution of inpp5ka and inpp5kb at 5 dpf by RNA scope in situ. A–Cinpp5ka shows even distribution in the brain and eye (A, B), also labeling lens cells (B). Muscle expression is sparse and at lower levels (C). D–Finpp5kb brain expression is highest in the pineal gland (arrow in D). Increased expression is also noted in the inner nuclear layer of the retina with lower expression in photoreceptors, retinal ganglion cells, and lens cells (E, also see Suppl. Figure 1B). Sparse expression is present in muscle cells (F, also see Suppl Fig. 1C). G–I Merged images including both probes (inpp5ka in green and inpp5kb in red) and DAPI to counterstain the nuclei. Scale bars: 100 µm for (A), (D), and (G), 50 µm for all other panels

Expression Data

Genes:	inpp5ka inpp5kb
Fish:	WT
Anatomical Terms:	brain epiphysis eye photoreceptor cell lens muscle retinal ganglion cell retinal inner nuclear layer retinal neural layer
Stage:	Day 5
