FIGURE

Fig. 4

ID

ZDB-FIG-190524-11

Publication

Emerson et al., 2018 - Developmental expression patterns of protein kinase A catalytic subunits in zebrafish

Other Figures

All Figure Page

Back to All Figure Page

Fig. 4

prkacβa neuronal expression patterns. Brightfield images of zebrafish embryos processed for in situ hybridization. (A–C) Whole-mount lateral, (A′-C′) whole-mount dorsal. Brightfield sections (A″-C″) forebrain, (A‴-C‴) midbrain and (B‴‘-C‴‘) hindbrain. Embryos were imaged at different developmental time points. (A-A‴) 24 hpf, (BB‴‘) 48 hpf, (CC‴‘) 72 hpf. Lines in (A–C) indicate locations of the sections shown at that time-point. Hpf-hours post fertilization, FBfin bud, OpV- optic vesicle, OV otic vesicle, lTeO- lateral optic tectum, RGC- retinal ganglion cell layer, lfb-lateral forebrain bundle, Hi-intermediate hypothalamus, INL-inner nuclear layer, T-thalamus, TeO optic tectum, MO- medulla oblongata, n.s-non-specific. Inset shows sense probe control.

Expression Data

Gene:	prkacba
Fish:	AB
Anatomical Terms:	fin bud forebrain hatching gland hypothalamus medulla oblongata midbrain optic cup optic tectum otic vesicle retinal ganglion cell layer retinal inner nuclear layer thalamus
Stage Range:	Prim-5 to Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 31, Emerson, S.E., Grebber, B.K., McNelllis, M., Orr, A.R., Deming, P.B., Ebert, A.M., Developmental expression patterns of protein kinase A catalytic subunits in zebrafish, 1-6, Copyright (2018) with permission from Elsevier. Full text @ Gene Expr. Patterns
