FIGURE
Fig. 1
- ID
- ZDB-FIG-180727-3
- Publication
- de Calbiac et al., 2018 - Depdc5 knockdown causes mTOR-dependent motor hyperactivity in zebrafish
- Other Figures
- All Figure Page
- Back to All Figure Page
Fig. 1
depdc5 expression in early development in the zebrafish larva. (A) Ventral view of a 28 hpf embryo showing expression of the depdc5 transcript in the telencephalon. (B) In situ hybridization using the control probe showing no positive signal. (C and D) Lateral and dorsal views, respectively, of the 28 hpf embryo showing the expression pattern in the brain and spinal cord. (E) RT‐PCR detecting Depdc5 expression in tissue obtained from zebrafish larvae at different stages of development.
|
Expression Data
| Gene: | |
|---|---|
| Fish: | |
| Anatomical Terms: | |
| Stage Range: | Shield to Protruding-mouth |
Expression Detail
Antibody Labeling
Phenotype Data
Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Ann Clin Transl Neurol
