Fig. 6

RacGAP1 depleted cells survive if cytokinesis is prevented. Row (1) phenotypic wild type, row (2) homozygous hrp mutants, and row (3) homozygous zom mutants. Row 1 and 2 are siblings. Column (A-C) uninjected embryos; column (D-F) morpholino (MO) knockdown embryos. (A, D) Live embryos, (B, E) DAPI stained nuclei: red arrowheads indicate sister nuclei where both nuclei are arrested in prophase; red arrow indicates two sister nuclei where one nuclei is in prophase and the other nuclei is in metaphase; yellow arrowheads indicate sister nuclei where both nuclei are in interphase; and yellow arrow indicates two sister nuclei where one nuclei is in interphase and the other nuclei is in prophase, and (C, F) anti-active Caspase 3 stained embryos.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	cdc20^ta94/ta94 fbxo5^ti245/ti245 WT + MO1-racgap1 cdc20^ta94/ta94 + MO1-racgap1 fbxo5^ti245/ti245 + MO1-racgap1
Knockdown Reagent:	MO1-racgap1
Observed In:	cell cell mitotic metaphase cell mitotic prophase cytokinesis mitotic cell cycle whole organism apoptotic process
Stage Range:	10-13 somites to 14-19 somites
