FIGURE

Fig. 1

ID

ZDB-FIG-160311-36

Publication

Assis et al., 2016 - INSL3 stimulates spermatogonial differentiation in testis of adult zebrafish (Danio rerio)

Other Figures

All Figure Page

Back to All Figure Page

Fig. 1

Morphological characteristics of zebrafish type A undifferentiated (A_und) and type A differentiating (A_diff) and type B spermatogonia and Leydig cells and in situ hybridization for insl3 mRNA in adult zebrafish testis. a Type A_und spermatogonia (arrow) are single germ cells showing a large and clear nucleus, with poorly condensed chromatin and one or two compact nucleoli. b A cyst containing two type A_diff spermatogonia (arrowhead) that show smaller nuclei stained more intensely by toluidine-blue. Type B spermatogonia (thin arrow) have still smaller, slightly elongated/ovoid nuclei that moreover show a high amount of heterochromatin. c Interstitial space (dashed line) with a group of Leydig cells. d Adult zebrafish testis section showing the detection of insl3 mRNA by in situ hybridization in Leydig cells cluster (dashed lines). Inset in d non-specific staining obtained with the sense probe. a-c Sections were prepared for morphological analysis according to Leal et al. (2009b). Magnification ×1000 (a, b), ×600 (c, d). Bars 10 µm

Expression Data

Gene:	insl3
Fish:	WT
Anatomical Term:	Leydig cell
Stage:	Adult

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
