FIGURE

Fig. 3

ID

ZDB-FIG-160307-1

Publication

De Martino et al., 2000 - Expression of sox11 gene duplicates in zebrafish suggests the reciprocal loss of ancestral gene expression patterns in development

Other Figures

All Figure Page

Back to All Figure Page

Fig. 3

Expression of sox11a and sox11b during early development. A,B: Anterior dorsal views of whole-mount 1-somite stage embryos. C,D: Flat mounts of 1-somite stage embryos, labeled with mRNA probes for sox11a and sox11b(blue) and with krox20 (red). A-D: Anterior to the left. Arrow heads mark krox20 staining, representing prospective rhombomeres r3 and r5. Both sox11a and sox11b share an anterior medial domain of expression. In addition, sox11a is expressed as a broad stripe just anterior to, and overlapping with, the krox20 stripe in prospective rhombomere 3. In contrast, sox11b is expressed most highly between the krox20 stripes in prospective rhombomere 4, and weakly more posteriorly. Scale bar = 100 µm.

Expression Data

Genes:	sox11a sox11b
Fish:	WT
Anatomical Terms:	axis neural plate anatomical margin presumptive rhombomere 2 presumptive rhombomere 3 presumptive rhombomere 4
Stage:	1-4 somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
