Fig. 4

ID

ZDB-FIG-150720-4

Publication

Huysseune et al., 2014 - Wnt signaling during tooth replacement in zebrafish (Danio rerio): pitfalls and perspectives

Other Figures

All Figure Page

Back to All Figure Page

Fig. 4

Figure 4. Dentition in mbl and apc mutant zebrafish. Dentition in WT (A) and mbl mutants (B) at 5dpf, and WT (C) and apc mutants (D) at 3 dpf. Insets: WT (A) and mbl mutant (B) at 6 dpf, and WT (C) and apc mutant (D) at 2 dpf. Color codes for arrowheads as in Figure 3. Note the complete similarity in tooth pattern between 5 dpf WT (A) and mbl mutants (B), and the substantial developmental delay in 3 dpf apc mutants (D) compared to WT fish (C), as can be observed from the large amount of yolk (y) still present, the thin endodermal layer covering the yolk (black arrowhead), and the absence of cartilage in the neurocranial base flanking the notochord (nc). Ov, otic vesicle. Note that sections are slightly oblique and different sets of teeth are visible on either body side. Scale bars = 50 µm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	apc^hu745/hu745 axin1^tm213/tm213
Observed In:	embryo development eye forebrain head pharynx replacement tooth 4V tooth 3V tooth 4V tooth 5V tooth placode yolk
Stage Range:	Protruding-mouth to Day 5

Phenotype Detail
