Fig. 3

hoxb1a and hoxb1b are required for neuronal differentiation in the hindbrain. 48hpf wild type (A, F), hoxb1a^-/-(B, G), hoxb1b^-/-(C, D, H, I) or doubly hoxb1a^-/-;hoxb1b^-/- embryos (E, J) were assayed by immunostaining for the differentiation of branchiomotor neurons (islet1/2 staining in A-E) and Mauthner neurons (3A10 staining in F-J). Colored arrowheads indicate r4 (yellow), r5 (blue) and r6 (red). All embryos are flat mounted in dorsal view with anterior to the top.

Expression Data

Antibodies:	Ab-3A10 Ab2-isl
Fish:	WT hoxb1b^um197/um197 hoxb1a^um191/+; hoxb1a^um192/+ hoxb1a^um193/+; hoxb1a^um194/+; hoxb1b^um197/um197
Anatomical Terms:	branchiomotor neuron cranial motor neuron facial nerve motor nucleus Mauthner neuron
Stage:	Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	hoxb1b^um197/um197 hoxb1a^um191/+; hoxb1a^um192/+ hoxb1a^um193/+; hoxb1a^um194/+; hoxb1b^um197/um197
Observed In:	cranial motor neuron facial nerve motor nucleus facial nerve motor nucleus motor neuron migration Mauthner neuron rhombomere 4 rhombomere 6 rhombomere 7
Stage:	Long-pec

Phenotype Detail
