FIGURE

Fig. S3

ID

ZDB-FIG-131213-6

Publication

Geng et al., 2013 - Semicircular canal morphogenesis in the zebrafish inner ear requires the function of gpr126 (lauscher), an adhesion class G protein-coupled receptor gene

Other Figures

All Figure Page

Back to All Figure Page

Fig. S3

Expression of the myelin basic protein gene (mbpa) is lost or reduced in the posterior lateral line ganglion and nerve in lauscher mutants. (A-H) Whole mount in situ hybridisation at 5 days post fertilisation shows a reduction in mbpa (mbp) expression in Schwann cells of the posterior lateral line ganglion (asterisks) and nerve (arrowheads) in the hypomorphic tb233c homozygotes (B) and tb233c/tk256a transheterozygotes (D); expression is lost in tk256a (F) and fr24 homozygotes (H). Lateral views. Scale bar: 100μm throughout.
