Fig. 4
- ID
- ZDB-FIG-130117-51
- Publication
- Chu et al., 2012 - Yolk syncytial layer formation is a failure of cytokinesis mediated by Rock1 function in the early zebrafish embryo
- Other Figures
- All Figure Page
- Back to All Figure Page
Rock1, but not Rock2a, is necessary for YSL formation in the zebrafish embryo.> (A) Protein domains of Rock1 and Rock2a and the putative dominant-negative (dn) construct. (B) Schematic of single-cell injection into the 2-cell stage embryo. (C) Embryos at oblong stage were stained for β-tubulin (white), F-actin (red) and DNA (blue). Images are projections of multiple focal planes. Arrowheads in Ci′,i′′ indicate a mitotic cell in late anaphase. Injection of dn-Rock2a (Cii–ii′′) did not affect YSL formation. Injection of dn-Rock1 (Ciii–iii′′) caused expansion of the YSL. (D) Statistical data for embryos expressing dn-Rock1 showing dose-dependent YSL expansion. |
