Fig. 7

The effect of fn1 and itga5 double knockdown on the interrenal tissue and the peri-interrenal vasculature.

Transverse sections of Tg(kdrl:EGFP)^s843 embryos injected with either STD-MO or fn1/itga5 antisense morpholinos, harvested at 2 dpf and visualized for 3β-Hsd activity (black) and GFP (green). All sections are oriented with the posterior end toward top of page. The fn1/itga5 double morphant phenocopied either fn1 or itga5 morphant in both migration and vessel formation of the interrenal tissue (IR, white arrow). Yellow arrows indicate the IRV sprouting from the DA. Abbreviations: notochord (NC), interrenal tissue (IR), interrenal vessel (IRV), dorsal aorta (DA).

Expression Data

Gene:	EGFP
Fish:	s843Tg s843Tg + MO2-itga5 + MO3-fn1a + MO3-itga5
Knockdown Reagents:	MO2-itga5 MO3-fn1a MO3-itga5
Anatomical Terms:	dorsal aorta interrenal angiogenic sprout
Stage:	Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	s843Tg + MO2-itga5 + MO3-fn1a + MO3-itga5
Knockdown Reagents:	MO2-itga5 MO3-fn1a MO3-itga5
Observed In:	interrenal angiogenic sprout interrenal primordium interrenal primordium left side interrenal primordium right side
Stage:	Long-pec

Phenotype Detail
