Fig. 10

Staining pattern of acetylated tubulin antibody in hindbrain region of spacehead and fala-like classes of mutants at 28 hpf. (A) Wild-type. Normal ladder array of longitudinal fascicles with commissural tracts in each hindbrain segment. (B) endeavorm591. Mild phenotype. (C) uchu hikoushi^m172. (D) saturn^m465. (E) m569. (F) ,em>lost and found^m236. (B-F) Variability of mutant phenotypes. Longitudinal fascicles and commissural tracts are less fasciculated in mutants. Commissural tracts appear to be diminished or to cross the midline in aberrant positions. Dorsal view onto hindbrain. Viewed with DIC optics, anterior to the left. com, commissural tract; llf, lateral longitudinal fascicle; mlf, medial longitudinal fascicle; tgm, trigeminal ganglion. Scale bar, 100 µm.

Expression Data

Antibody:	Ab1-tuba
Fish:	AB end^m591/m591 (AB) lot^m236/m236 (AB) sat^m465/m465 (AB) uhi^m172/m172 (AB) unm_m569^m569/m569 (AB)
Anatomical Terms:	hindbrain white matter lateral longitudinal fasciculus medial longitudinal fasciculus trigeminal ganglion
Stage:	Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	end^m591/m591 (AB) lot^m236/m236 (AB) sat^m465/m465 (AB) uhi^m172/m172 (AB) unm_m569^m569/m569 (AB)
Observed In:	hindbrain commissure lateral longitudinal fasciculus medial longitudinal fasciculus
Stage:	Prim-5

Phenotype Detail
