Fig. 4

Mutations in the genes freixenet (frx) and yquem (yqe) cause erythropoietic porphyria phenotypes. Mutant and wild-type embryos were examined under 330 to 380 nm UV light for autofluorescence. (A) A wild-type 2- day old embryo does not have autofluorescent blood. (B) The blood of 2-day old frx^tu271 homozygotes is brightly autofluorescent under the same conditions. (C) The blood of 2-day old yqe^tp61 homozygotes is also autofluorescent. In addition, the yqe^tp61 mutants rapidly develop pericardial edema when exposed to bright light.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	fech^tu271/tu271 urod^tp61/tp61
Conditions:	lighting conditions ultraviolet light
Observed In:	blood circulation fin hemoglobin biosynthetic process nucleate erythrocyte pericardium whole organism (all 6)
Stage:	Long-pec
