Fig. 7

ponzr1 is required for wt1b-expressing pharyngeal arches. (A) A drawing of a 3 dpf larval zebrafish showing where the pharyngeal arches are located. The green box is the area seen in images B and C. (B) Tg(wt1b:EGFP) larvae 3 dpf lateral view shows three pharyngeal arches express wt1b. (C) When ponzr1 MO is injected, the pharyngeal arches are lost. (D) The loss of pharyngeal arches phenotype is significantly different in the two ponzr1 MOs compared with both the wild type and mismatch controls. ^**P<0.01, ^***P<0.001

Expression Data

Gene:	EGFP
Fish:	li1Tg li1Tg + MO1-ponzr1
Knockdown Reagent:	MO1-ponzr1
Anatomical Term:	pharyngeal arch
Stage:	Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	WT + MO1-ponzr1 WT + MO2-ponzr1
Knockdown Reagents:	MO1-ponzr1 MO2-ponzr1
Observed In:	pharyngeal arch
Stage:	Protruding-mouth

Phenotype Detail
