FIGURE

Fig. 5

ID

ZDB-FIG-111007-24

Publication

Linney et al., 2011 - Identification and characterization of a functional zebrafish smrt corepressor (ncor2)

Other Figures

Fig. 5

All Figure Page

Back to All Figure Page

Fig. 5

In situ hybridization of zebrafish corepressors in 8 cell embryos. To the left is expression of smrt and to the right is expression of ncor. This is at a time before the embryonic genome is turned on. Similar results for rar aa, rar ab, hdac3, rxr ga and rxr ab for 8 cell embryos and oocytes indicating that these necessary components for repression are present at fertilization. These are consistent with results of others identifying early embryonic expression of these genes (Bertrand et al., 2007) (Xu et al., 2009) (Waxman and Yelon, 2007). Using quantitative RT-PCR we have confirmed the presence of z smrt and z ncor in cDNAs from four separate 1–8 cell RNA extractions.

Expression Data

Genes:	ncor1 ncor2
Fish:	WT
Anatomical Term:	whole organism
Stage:	8-cell

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene, 486(1-2), Linney, E., Perz-Edwards, A., and Kelley, B., Identification and characterization of a functional zebrafish smrt corepressor (ncor2), 31-6, Copyright (2011) with permission from Elsevier. Full text @ Gene
