Fig. 4

Cell morphology is disrupted by Git2a knockdown. Representative images of cortical actin (red) and Git2 (green) distribution in EVL cells of control and git2a morphant embryos at 75% epiboly. Git2 expression was reduced and cell morphology, outlined by cortical actin, was significantly altered in git2a morphants. Scale bar, 50 μm. Animal pole region (upper row) and lateral region (lower row) demonstrated in control and Git2a morphant embryo are schematically represented on the right (Kimmel et al., 1995).

Expression Data

Antibody:	Ab1-git
Fish:	AB AB + MO1-git2a
Knockdown Reagent:	MO1-git2a
Anatomical Term:	EVL
Stage:	75%-epiboly

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	AB + MO1-git2a
Knockdown Reagent:	MO1-git2a
Observed In:	EVL cell
Stage:	75%-epiboly

Phenotype Detail
