Fig. 2

Analysis of pharyngeal arch organization in wild-type and radar mutant larvae. A,B: Lateral and ventral view of Alcian blue stained 5 days postfertilization (dpf) wild-type larvae. C: High magnification of dotted box area in A noting normal articulation of ceratohyals (at joint indicated by black arrow) and normal positions of ceratobranchials (red arrows) D: Camera lucida image outlining the Alcian blue stained cartilages in B. E: Collagen-2α1 staining of the third arch in 5 dpf wild-type larvae to visualize ceratobranchial, basibranchial, and hypobranchial. F,G: Lateral and ventral view of Alcian blue radars327 mutant. H: High magnification of region in panel F demarcated by dotted box showing abnormal articulation of ceratohyals (black arrow) and more sharply angled ceratobranchials (red arrows). I: Camera lucida image of the Alcian blue stained cartilages in E. J: Collagen-2α1 staining of third arch in 5 dpf mutant larvae reveals morphological abnormalities of the hypobranchial (asterix) and hypobranchial/ceratobranchial joint (arrow). ch, ceratohyals; cb, ceratobranchials; bb, basibranchial; hb, hypobranchials.

Expression Data

Expression Detail
Antibody Labeling
Phenotype Data
Fish:
Observed In:
Stage: Day 5

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
