Fig. 6

Analysis of detached fibres indicates that muscle attachment failure occurs external to the sarcolemma. Whole-mount immunohistochemistry of mutant embryos at 72 hpf reveals the presence of dystrophin and β-dystroglycan at the ends of detached fibres. (A-F) Wild-type (A-C) and sof (D-F) embryos stained with anti-dystrophin. (G-L) Wild-type (G-I) and sof (J-L) embryos stained with anti-β-dystroglycan. (A,D,G,J) DIC images, (B,E,H,K) fluorescence images, (C,F,I,L) merged images. Arrows indicate fibre detachments. All panels show lateral views with anterior to the left. dys, anti-dystrophin; bDG, anti-β-dystroglycan.

Expression Data

Genes:	dag1 dmd
Antibodies:	Ab1-dmd Ab4-dag1
Fish:	WT lamb2^{tm272a/tm272a}
Anatomical Terms:	skeletal muscle cell sarcolemma vertical myoseptum
Stage:	Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	lamb2^{tm272a/tm272a}
Observed In:	muscle attachment myotome muscle cell myotome myoseptum vertical myoseptum
Stage:	Protruding-mouth

Phenotype Detail
