FIGURE

Fig. 6

ID

ZDB-FIG-090618-22

Publication

Vlecken et al., 2009 - A critical role for myoglobin in zebrafish development

Other Figures

All Figure Page

Back to All Figure Page

Fig. 6

Effects of microinjection of myoglobin gene-specific morpholinos in Tg:fli1/eGFP and Gut/GFP transgenic fish. Tg:fli1/eGFP embryos (A, D-J) and Gut/GFP (Tg:ef-1α/eGFP) (B,C,K) were injected with 4 ng/embryo of either Control Morpholino (Co) or Mb specific Morpholino (Mo) as indicated. Zebrafish larvae at three different time points are shown: 3 dpf, 4 dpf and 5 dpf. The fluorescent gut is not well visible before 4 dpf. All pictures show confocal images of representative examples for control and knock down embryos. Higher magnification images (H,J) give examples for a control (H) and an Mb knock down (J) embryo, respectively. An asterisk is used to mark representative sites of vascular defects (E-G, I,J) (not all defects are marked).

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	s854Tg + MO1-mb y1Tg + MO1-mb
Knockdown Reagent:	MO1-mb
Observed In:	dorsal longitudinal anastomotic vessel gut vasculogenesis
Stage Range:	Protruding-mouth to Day 5

Phenotype Detail
