FIGURE

Fig. 7

ID

ZDB-FIG-071228-31

Publication

Liao et al., 2007 - Expression and water calcium dependence of calcium transporter isoforms in zebrafish gill mitochondrion-rich cells

Other Figures

All Figure Page

Back to All Figure Page

Fig. 7

Double fluorescence in situ hybridizations of zecac/zpmca2 (A-C) and zecac/zncx1b (D-F) in frozen sections of zebrafish gills. A and D, zecac mRNA; B, zpmca2 mRNA; C, merged image of A and B; E, zncx1b mRNA; F, merged image of D and E. Arrow indicates the colocalization of zecac/zpmca2 (A-C) and zecac/zncx1 (D-F), respectively. An asterisk (*) indicates the zpmca2 signal without zecac colocalization (A and B) and the zncx1b signal without zecac colocalization (D and E). Scale bar = 20 μm.

Expression Data

Genes:	atp2b2 slc8a1b trpv6
Fish:	WT
Anatomical Term:	gill
Stage:	Adult
