Fig. 5

Blood fate is first expanded and then reduced upon progressive loss of BMP activity. gata1 expression at 10 somites in embryos from a cross between a triple bmp heterozygote and a bmp4^st72 heterozygote. (A) Wild-type phenotype exhibited by a bmp4^st72 heterozygote. Expansion of the gata1 expression domain ventral to the tailbud is evident in a bmp4^st72 homozygote (B) and a bmp4^st72/bmp4^st72; snh^ty68a/+ embryo (C). Reduction of the gata1 expression domain is observed upon further reduction of BMP, as in these bmp4^st72/bmp4^st72; swr^ta72/+ (D) and bmp4^st72/bmp4^st72; snh^ty68a/+; swr^ta72/+ (E) embryos, although ectopic gata1 expression ventral to the tailbud is still apparent.

Expression Data

Gene:	gata1a
Fish:	bmp4^st72/st72 bmp4^st72/+ bmp2b^ta72a/+; bmp4^st72/st72 bmp4^st72/st72; bmp7a^ty68a/+ bmp2b^ta72a/+; bmp4^st72/+; bmp7a^ty68a/+
Anatomical Terms:	mesoderm tail bud
Stage:	10-13 somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 310(1), Stickney, H.L., Imai, Y., Draper, B., Moens, C. and Talbot, W.S., Zebrafish bmp4 functions during late gastrulation to specify ventroposterior cell fates, 71-84, Copyright (2007) with permission from Elsevier. Full text @ Dev. Biol.
