FIGURE

Fig. 5

ID

ZDB-FIG-070314-53

Publication

Mills et al., 2007 - Deconstructing evolution of adult phenotypes: genetic analyses of kit reveal homology and evolutionary novelty during adult pigment pattern development of Danio fishes

Other Figures

All Figure Page

Back to All Figure Page

Fig. 5

kit is required during a late step in melanophore development. Dorsal regions of late larval fish are shown before (A-D) and after (A'-D') incubation with L-dopa. Arrowheads, sites of melanoblasts before and after L-dopa treatment. (A,A') In wild-type D. rerio, previously melanized melanophores are present within the dorsal melanophore stripe and on dermal scales (arrow). Very few L-dopa⁺ melanoblasts are revealed (arrowheads). (B,B') kit mutant D. rerio exhibit more undifferentiated melanoblasts than wildtype D. rerio. (C,C') In wild-type D. albolineatus, many more L-dopa⁺ melanoblasts are present than in wild-type D. rerio. (D,D') kit mutant D. albolineatus have similar numbers of L-dopa⁺ melanoblasts to wild-type D. albolineatus.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	kita^b5/b5 (AB)
Observed In:	melanoblast melanocyte
Stage:	Unknown

Phenotype Detail
