Fig. 3

Expression of tsh1 is affected by retinoic acid signaling. (A–C) Expression of tsh1 expression in mock (A) and RA (B–C) treated embryos. (C) A dorsal view (anterior to the top) of the embryo in (B). (D, E, F, G and H) Lateral or dorsal view of tsh1 expression in wild-type and (I, J, K, L and M) neckless (nls) mutants. At 24 hpf, tsh1 expression in the spinal cord is markedly reduced in the nls mutant embryo (I) compared to wild-type siblings (D). Between 48 and 72 hpf, nls mutants (J, K, L and M) exhibit reduced tsh1 expression in the tectum, eyes, the midbrain–hindbrain boundary and the hindbrain. Abbreviations: mhb, mid–hindbrain; tec, tectum opticum; t, telencephalon; ob, olfactory bulb; h, hindbrain.

Expression Data

Gene:	tshz1
Fish:	WT aldh1a2^i26/i26
Condition:	chemical treatment: all-trans-retinoic acid
Anatomical Terms:	cerebellum eye forebrain hindbrain immature eye mandibular arch skeleton midbrain midbrain hindbrain boundary olfactory bulb optic tectum spinal cord telencephalon
Stage Range:	Prim-5 to Protruding-mouth

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
