FIGURE

Fig. S1

ID

ZDB-FIG-060324-6

Publication

Muto et al., 2005 - Forward Genetic Analysis of Visual Behavior in Zebrafish

Other Figures

All Figure Page

Back to All Figure Page

Fig. S1

Pineal Photoreceptors Are Present in Retinal Photoreceptor Degeneration Mutants Coronal sections of the forebrain at 7 dpf were stained with DAPI (A, C, E, and G) and zpr1, a marker of both retinal and pineal photoreceptors (B, D, F, and H). Pineal photoreceptors (arrow and inset) were consistently present in mutants in which retinal photoreceptors were depleted (D, F, and H). Scale bar is 100 μm for A-J and 25 μm for the insets.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	ssd^s386/s386 mti^s528 pday^s351
Observed In:	epiphysis photoreceptor cell eye photoreceptor cell
Stage:	Days 7-13

Phenotype Detail
