Fig. 4

Somite maturation but not segmentation pattern is regulated by RA. 15-somite (A–C) and 10-somite (D–L) stage embryos are displayed as in Fig. 2. (A–C) At the 15-somite stage, twist is expressed in sclerotome. twist expression is reduced in DEAB-treated embryos (B) and increased in RA-treated embryos (C). (D–I) The segmented pattern (arrows) of mesp-b (D–F) and papc (G–I) is not modified by either DEAB or RA treatments. (J–L) paraxis is expressed in anterior psm (bracket) and somites. Expression of paraxis in DEAB-treated embryos is similar to that in control (K) while it is extended posteriorly in RA-treated embryos (L; bracket). Scale bars: in panel A, 100 μm for panels A–C; in panel D, 100 μm for panels D–L.

Expression Data

Genes:	mespba pcdh8 tcf15
Fish:	WT
Conditions:	chemical treatment by environment: 4-(diethylamino)benzaldehyde chemical treatment: all-trans-retinoic acid
Anatomical Terms:	segmental plate somite
Stage:	10-13 somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 289(1), Hamade, A., Deries, M., Begemann, G., Bally-Cuif, L., Genet, C., Sabatier, F., Bonnieu, A., and Cousin, X., Retinoic acid activates myogenesis in vivo through Fgf8 signalling, 127-140, Copyright (2006) with permission from Elsevier. Full text @ Dev. Biol.
